Description
The GQTM-8608Q module able to generate a signal in DVB-T/C format from HDMI input.
GQTM-8608Q is H264 encoding, DVB-T/C modulation integrated device to convert HDMI signal to DVB-T/C RF out.
The GQTM-8608Q module adjusts the compression rate to the available bandwidth, using the modulation DVB-T/C parameters.
Specifications
| INPUT | |
| Input Channel | 4 |
| Input Connectors | HDMI |
| Video System | 480i/p, 576i/p, 720p, 1080i/p |
| RF OUTPUT | |
| Type | 1 F-type output ports for 2 carriers,75 Ω |
| Frequency | DVB-T: 177-858 MHz, DVB-C: 105~858MHz |
| Output Level | 95 dBµV Min. |
| RF Level Adjustment | 0 ~ -30dB |
| Attenuation step | 1dB per step |
| MER | 35dB Min. |
| MODULATION | |
| Video Resolution | 1080p 25/30 Max |
| Video Compression | H.264 Baseline Profile Level4.0 |
| Video Bit Rate | 12Mbps Max |
| Audio Compression | MPEG-2/AAC |
| Audio Bit Rate | 192Kbit/s |
| Editable Field | Service Name, Provider Name, Service ID, LCN, NIT Version, TS ID, Network Name, Network ID, Original Net ID, Country |
| DVB-T | |
| Standard | DVB-T (ETSI EN 300 744) |
| Carrier (OFDM Mode) | 8K |
| Guard Intervals | 1/32 |
| Code Rate (FEC) | 7/8 |
| Constellations | 64QAM |
| Bandwidth | 6MHz, 7MHz, 8MHz, 7-8MHz |
| DVB-C | |
| Standard | DVB-C (ETSI EN 300 429 V1.2.1) |
| Constellation | 16,32,64,128,256QAM |
| Symbol rate | 2.0~6.96 Msymbols |
| Bandwidth | 7MHz, 8MHz |
| MANAGEMENT / CONTROL | |
| Configuration | 6 Local keys on Upper cover |
| Web Management | RJ-45 Ethernet port |
| GENERAL | |
| Display | LCD panel @ 2 x 16 characters (on front panel) |
| Power Supply | AC 100~240V 50/60Hz |
| Consumption | 20 W |
| Languages | English |
| Dimensions | 19"x12.5"x1.75" |
| Weight | 2.8kg |
