GPT6621 Single-PON Port GPON OLT features a compact, portable design suitable for desktop deployment and supports wall-mount installation, effortlessly adapting to diverse scenarios. Combining robust performance with high cost-effectiveness, it serves as an optimal solution for ultra-low-cost deployment.
The built-in bottom fiber tray structure not only effectively protects the fiber and enhances operational safety but also simplifies fiber installation and maintenance processes. With a PON port splitter ratio of 1:64, it is suitable for low density scenarios, offering a maximum transmission distance of 20KM and uplink/downlink bandwidths of up to 1.25Gbps/2.5Gbps. It is widely applicable for FTTX, SOHO, and small business office environments.
Technical parameters
|
Item
|
GPT 6621
|
|
| Uplink Port | QTY | 3 |
| RJ45(GE) SFP(GE)/SFP+(10GE) |
2 | |
| 1 | ||
| GPON Port | QTY | 1 |
| Max splitting ratio | 0.084027778 | |
| Management Ports | 1 Type-C USB(for console) | |
| Backplane Bandwidth (Gbps) | 29 | |
| Port Forwarding Rate(Mpps) | 21.567 | |
| PON Port Specification | Transmission Distance | 20KM |
| GPON port speed | Upstream 1.244Gbps,Downstream 2.488Gbps | |
| Wavelength | TX 1490nm,RX 1310nm | |
| Connector | SC/UPC | |
| Fiber Type | 9/125μm SMF | |
| Management Mode | WEB,SNMP,Telnet,CLI | |
| Functions | Layer2 Switch,Multicast,DHCP,Layer 3 Route,IPv6 | |
| Weight | Net weight of single power:0.23kg | |
| Gross weight of single power:0.3kg | ||
| Dimension (L*W*H) | 144.5mm*140mm*36.5mm | |
| Power Consumption | 5W | |
| Temperature | Working Temperature:0°C~+60°C | |
| Storage Temperature:-40°C~+85°C | ||
