Describe
- No epoxy, fiber polishing, special tools, or fusion splicer required.
- Quick and easy fiber termiQuick and easy fiber termination in less than two minutesnation in less than two minutes.
- Precision mechanical alignment ensures low insertion loss.
- Superior optical performance.
Parameters & Specifications
| Connector Type | SC, Simplex |
| Cable Diameters | 0.9 / 2.0 / 3.0mm |
| Fiber Mode | Singlemode |
| Polish | UPC / APC |
| Insertion Loss | UPC: ≤0.35dB, APC: ≤0.35dB |
| Return Loss | UPC: ≥45dB, APC: ≥50dB |
| Tension Test | ≥50N |
| Operating Temperature | -40°C ~ +75°C |
| Quantity per package | 10 |
| Compliance | Designed to Telcordia GR-20-CORE, GR326 and TIA/EIA 568C, RoHS |
