Product Overview
The GD8XT is an 8-port multi-gigabit switch that offers advanced high-bandwidth performance, ease of use, and high reliability. This multi-gigabit switch provides eight dedicated 10G ports for high-speed network connections, with a 160Gbps switching capacity and a sturdy rack-mountable metal housing. This 10G switch is an economical solution for high-speed 10 Gigabit network connections.
Features
● 8* 1G/2.5G/5G/10G Base-T RJ45 port
● Compatible with existing Cat6A or better cabling
● 160Gbps switching capacity
● Backwards compatible with 1000M/2.5G/5Gbps rate
● Carrier-grade device stability and network resilience
● Laye3 static routing support
● Enhanced security mechanisms
● Unified network management
Hardware Specifications
| Attributes | GD8XT | |||
| Protocol | IEEE 802.3,802.3az,802.3ae,802.3x,802.3ad,802.1x,802.1Q,802.1p,802.1d,802.1w | |||
| Ethernet Port | 8* 1G/2.5G/5G/10G Base-T RJ45 port | |||
| Console Ports | 1* RJ45 | |||
| Chipset | RTL9303+8* RTL8261BE | |||
| Switching Capacity | 160Gbps | |||
| Forwarding Rate | 119.05Mpps | |||
| MAC Address | 16K | |||
| Jumbo Frame | 12K Byte | |||
| Packet Buffer | 12Mbit | |||
| LED | PWR, LINK/ACT, SYS | |||
| Flash | 32MB | |||
| DDR Memory | 512MB | |||
| Power Supply | 12V/4A | |||
| Power Consumption | ≤36W | |||
| Dimensions | 207× 136×35mm | |||
| Working Temperature | -10℃ ~ 50℃ | |||
| Storage Temperature | -40℃ ~ 70℃ | |||
| Working Humidity： | 10~90% Non-condensing | |||
| Storage Humidity | 5~90% Non-condensing | |||
